Stereo Zoom Microscope SPZV-50 [6.7x–50x] with Mighty Cam Eidos 4K Camera/Monitor on Double Arm Boom Stand

Stereo Zoom Microscope SPZV-50 [6.7x–50x] with Mighty Cam Eidos 4K Camera/Monitor on Double Arm Boom Stand

SKU: 26800B-711

UPC CODE: 766955377016

Description: This complete, high-performance inspection platform combines precision stereo optics with integrated 4K digital imaging. Built for detailed visual inspection, measurement, and documentation, the system delivers crisp 3D images with a wide field of view and smooth, continuous zoom—no PC required.

The stereo zoom microscope provides 6.7x–50x optical magnification, extending up to 143x when viewed on the integrated 11.6” 4K monitor. Ultra HD imaging, on-screen measurement, and image/video capture are all handled within the system, with HDMI output available for external display. Designed as a unified solution, this microscope system streamlines inspection workflows for quality control, medical device, R&D environments, and more

Magnification
SPZV-50 Microscope	6.7x - 50z
Mighty Cam Eidos 4K Screen	19x to 143x

VIEW ALL REVIEWS

$5,259.83

Guaranteed safe checkout:

Orders ship within 5 to 10 business days.

Hoorey ! This item ships free to the US

Designed for Ergonomic Inspection

Extended microscope use has long been associated with eye strain and musculoskeletal fatigue. Traditional optical microscopes often force operators into fixed, awkward postures — bending the neck, leaning forward, and limiting natural movement.

The Mighty Cam Eidos 4K system is designed to overcome these challenges. Its integrated 11.6” high-definition display positions the inspection image at eye level, allowing operators to work comfortably in a neutral posture. This reduces fatigue while improving focus and productivity during long inspection sessions.

When optical viewing is required, the microscope remains fully functional — providing the best of both digital and traditional inspection methods.

SPZV-50 Stereo Zoom Microscope

The SPZV-50 true trinocular stereo zoom microscope offers a best-in-class zoom ratio with sharp, high-contrast 3D images, wide field of view, and long working distance — making it ideal for inspection, documentation, and digital imaging.

Magnification ranges from 3.35× to 200× with optional auxiliary lenses and eyepieces. A wide selection of stands, illumination, and camera options allows the system to be configured for virtually any inspection requirement.

Mighty Cam Eidos 4K

Digital Inspection Made Easy

Eliminates Eye Strain and Operator Fatigue

The Mighty Cam Eidos 4K features a high-performance 8.29MP CMOS sensor (1/1.8”) delivering 4K Ultra HD resolution (3840 × 2160 @ 30 FPS). When mounted to a trinocular microscope or video lens using its standard C-mount, the system delivers exceptional clarity, contrast, and color accuracy.

The integrated 11.6” HD display allows users to inspect comfortably without eyepieces, dramatically reducing eye strain and physical fatigue.

4K Image and Video Capture

Capture and Save 4K Images and Video

No Computer Required

Save ultra-high-resolution 4K images and video directly to a MicroSD card. No PC or external software is required, enabling fast documentation and easy review without disrupting workflow.

HDMI and USB-C Outputs

The Mighty Cam Eidos 4K includes HDMI and USB-C outputs for flexible connectivity. HDMI allows simultaneous viewing on the built-in display and an external monitor.

The USB-C port supports data transfer and integration with third-party imaging software. (Software not included.)

Integrated Measurement Software

The built-in computational imaging software enables accurate, on-screen measurement without a PC.

Calibration editor
Radius and diameter measurement
2- and 3-point circle tools
Crosshair and line measurement tools
Center distance and concentric circle measurements
Annotation and screenshot capture tools

Mighty Cam Eidos 4K

Convenient 2-in-one camera and monitor system
Simple cable management
Crisp 4K Ultra HD image
Built in USB port for instant image/video capture
USB output for connection to your PC
Wireless mouse for access to settings menus
Grid overlays
Compare mode, freeze mode and mirror mode
Alleviate the eye strain and neck fatigue associated with frequent microscope use

SPZV-50 Microscope

View images through the eyepiece or a monitor simultaneously.
Click stop zoom adjustment for accurate measuring
Easy adjust C-mount camera adapter for fine focusing
Large zoom ratio 7.46:1- best zoom ratio in class
Field of View 34.3mm to 3.6mm (1.35" to 0.14")
Working distance 108mm (4.25") – the best in class
17mm (0.67") high eye point wide field 10x eyepieces (field number 23) for comfortable
viewing even for operators with eyeglasses
Diopter adjustment on both eyepiece tubes

Specs

SPZV-50 Stereo Zoom Microscope
Body Type	True Trinocular, 360° rotatable, 45° inclined eyepiece tube & C-mount camera port
Eyepieces	Two 10x(FN23)eyepieces supplied with microscope body. Optional 15x(FN15) and 20x(FN11.4) available to extend magnification range
Auxiliary lens	0.5x, 0.75x, 1.6x and 2x auxiliary lenses available to extended magnification range of microscope
Working Distance	108mm without auxiliary lens 240mm with 0.5x auxiliary lens 132mm with 0.75x auxiliary lens 50mm with 1.6x auxiliary lens 41mm with 2x auxiliary lens
Zoom Ratio	7.46:1
Diopter Adjustment	On both eye tubes: +5.6D-.72D
Interpupillary Distance	Adjustable from 52 to 78.29 megapixelm
Optical System	Greenough
Package Contents	1ea SPZV True Trinocular Stereo Zoom Microscope Body with Photo tube 2 ea. 10x Eyepieces 2 ea. Rubber Eyeguards 1 ea. Dust Cover 1 ea. Instruction Manual
Weight	5lb

26100-261 Mighty Cam Eidos 4K
Hardware Parameters	Display Specification	11.6 inch, IPS Screen
	Imaging Sensor	1/1.8 inch CMOS
	Real-Time Image Frame Rate	4K Ultra HD 3840 x 2160px @ 30 FPS
	Photograph	8.29MP megapixel
	Video Recording	1920 x 1080 or 3840 x 2160px
	Output Interface	HDMI
	Input Interface	2 USB 2.0 Ports
Internal Software Parameters	Camera parameters	Exposure, White Balance, Gain, Gamma, Brightness, Contrast, Hue, Saturation, Grayscale
	OSD Operation	Mouse
	Storage Function	USB Storage, MicroSD Card
	Measurement	Line
		Parallel
		Lines
		Broken Lines
		Angle
		Diameter
		Circle
		Radius
		Circle
		Three-Point Circle
		Distance from circle to line
		Concentric Circles
		Double Circles
		Vertical Line
		Arbitrary Line
		Polygon
		Arc
		Mark
		Screenshot
		Table Data Export
		Calibration
		Parameter Settings
	Other Function	Flip horizontally, flip vertically, Freeze
	Scale Ruler	3 Options
	Grid Line	8 Groups
	Languages	English, French, Italian, German, Japanese, Russian, Simplified Chinese, Traditional Chinese
Package Content	Mighty Cam Eidos 4K Power Supply HDMI to HDMI Mini cable Wireless Mouse 16GB MicroSD Card USB-C to USB-A MicroSD Card Reader USB-C to USB-A Adapter for Wireless Mouse Transmitter USB-A Wireless Mouse Transmitter

Focus Mount Type	E-Arm (5/8" Adapter)
Illumination	Integrated 60 LED ring light with dimmer control
Diameter	74mm

Double Arm Boom Stand w/Heavy Metal Base
Base Size	288.29 megapixelm x 260mm x 18mm
Base Weight	17.35 kg (38lbs)
Base Size	288.29 megapixelm x 260mm x 18mm (11.22 x 10.23 x 0.70")
Vertical Post Length	380mm (15")
Vertical Extension Post	6" (154mm)
Vertical Post Diameter	37.2mm
Horizontal Arm Length	384mm
Horizontal Arm Diameter	20mm
Focus Mount Hole Diameter	15.878.29 megapixelm (5/8";)
Mounts Accepted	SCW-PA focus mount with tiltable arbor 26800B-521 or E-Arm
Accepted Bodies	SSZ, SPZ, DSZ and NSW series
Package Contents	One boom stand with metal base Users manual

Optical Data

Eyepiece | DHW10X (F.N. 23)

Auxiliary Lens	Nil	w/0.5x	w/0.75x	w/1.6x	w/2x
Magnifications	6.7x-50x	3.35x-25x	5x-37.5x	10.72x-80x	13.4x-100x
Working Dist.	108mm	240mm	132mm	50mm	41mm
Field of View	34.3-4.6mm	68.9-9.2mm	45.7-6.1mm	21.4-2.8mm	17.1-2.3mm

Eyepiece \| DHW15X (F.N.15)
Auxiliary Lens	Nil	w/0.5x	w/0.75x	w/1.6x	w/2x
Magnifications	10.05x-75x	5.02x-37.5x	7.53x-56.25x	16.08x-120x	20.1x-150x
Working Dist.	108mm	240mm	132mm	50mm	41mm
Field of View	22.3-3mm	44.7-6mm	29.8-4mm	16-1.8mm	11.1-1.8.29 megapixelm

Eyepiece \| DHW20X (F.N. 11.4)
Auxiliary Lens	Nil	w/0.5x	w/0.75x	w/1.6x	w/2x
Magnifications	13.4x-100x	6.7x-50x	10.05x-75x	21.44x-160x	26.8x-200x
Working Dist.	108mm	240mm	132mm	50mm	41mm
Field of View	17-2.2mm	34-4.8.29 megapixelm	22.6-3mm	10.6-1.4mm	8.5-1.1mm
